1/2" Simplex Basket Strainers PVC EPDM O-Ring - Skt/Thd

Simplex Basket Strainers are assembled with silicone free lubricant. Each Simplex Basket Strainer includes one plastic basket. If perforations is not specified, then standard basket perforation will be shipped.
Protect System Components: When pipeline system components require protection from dirt and debris and the line can be shut down for basket cleaning, a Hayward® All Plastic Simplex Basket Strainer is the ideal choice. Unwanted particles are removed as the process media passes through a perforated strainer basket contained inside the strainer body. The basket traps the unwanted material while allowing the process media to flow freely.
Easy Basket Cleaning: Changing or cleaning the strainer basket is quick and easy. The hand-removable, spin-off cover features two angled handles for easy access to the strainer basket. The housing features external cover threads that do not contact the process media and never need cleaning. Venting and draining are made possible by two hand-removable, threaded plugs - one on the top of the cover and the other on the housing side.
Choice of Piping Connections: Hayward® Simplex Basket Strainers can be installed either in-line or with loop piping configurations. This is made possible by a unique design that incorporates three piping connections on the strainer body that are used as inlets and outlets. The unused connection is plugged using a blind fitting (included). True Union connections make it possible to remove the strainer from the piping system without disassembling the piping connections.
Wide Range of Strainer Baskets: Plastic Baskets in perforation sizes from 1/32" to 3/16" are available. Stainless steel perforated baskets are available from 1/2" to 1/32". Mesh stainless steel baskets for very fine straining applications are available in sizes from 20 mesh down to 325 mesh.

Model Number: SB1050STE
Part Number: 12-4387

Length: 10.7700 in
Height: 10.7700 in
Weight: 8 lb

Your Price: CALL

Call for competitive pricing or to locate a distributor in your area (877) 734-3759

All dimensions and weights are approximate to the best of our knowledge. If exact size tolerances are required please contact our customer service department prior to ordering.
